800LE+ Self-propelled Concrete Floor Grinder With Gear-driven 800LE+ Self-propelled floor grinder and versatile polisher are used to grind (rough grind, fine grind, and polish) concrete, natural stone and terrazzo floors or other materials. With a self-propelled function, it realizes higher grinding efficiency with lower labor costs. The design of the planetary rotating system makes the grinding effect uniform and stable. More
GX550 Concrete Floor Grinder GX550 Concrete Planetary Grinding machine has 3 planetary heads with very low maintenance. The stronger welded machine body with friendly operation handle and 2 positions weight iron to adjust the pressure when you are working. All motor and inverter are from the newest technology special for XINGYI grinding machine. More
Heavy-Duty Remote Control Planetary Concrete Grinding Machine XINGYI GX858 GX858 Concrete Grinder is a remote control heavy-duty equipment for your polishing project, the machine has 4 planetary heads with very low maintenance. The stronger welded machine body with friendly operation handle and 2 positions weight iron to adjust the pressure when you are working. All motor and inverter are from the newest technology special for XINGYI grinding machine. More
Ride on floor grinder Tank1500 is a very suitable for industrial applications, low-maintenance, smooth-running on-board grinding and polishing machine, gearbox, completely sealed and dustproof. More
GX750 Heavy-Duty Concrete Grinding Machine GX 750 Planetary Concrete GRINDING MACHINE GX750 is a heavy-duty equipment for your polishing project, Thanks to XINGYI dual Alloy gearbox casting technology, the machine has 3 planetary heads with very low maintenance. The stronger welded machine body with friendly operation handle and 2 positions weight iron to adjust the pressure when you are working. All motor and inverter are from the newest technology special for XINGYI grinding machine. More
GX650 Concrete Grinding and Polish machine GX 650 / GX 65 ROTARY Concrete GRINDING MACHINE The GX650 has 4-heads which works in counter rotary direction and provide smooth of operation and handling. Collapsible hand grip for easier transport and adjustable to your perfect working position. Dual-purpose additional weight makes your construction easier.Its versatile function from floor preparation to fine polishing, suitable for concrete, stone, epoxy coating, terrazzo and other floors. The 17 years of classic design with worry-free quality.*GX65 is equipped with fixed handle. More
GX550 Concrete Floor Grinder GX550 Planetary concrete grinder,Same with other GX series machine, the machine has 3 planetary heads with very low maintenance. The stronger welded machine body with friendly operation handle and 2 positions weight iron to adjust the pressure when you are working. All motor and inverter are from the newest technology special for XINGYI grinding machine. More
955LE large polishing floor grinding machine Features and Advantages 1.Intelligent remote control, millisecond response. 2. S-type grinding greatly improves the grinding force. 3. The equipment comes with a spray system:The spray system can quickly reduce the temperature of the abrasive to improve the grinding efficiency. Using the spray function can also reduce dust. 4. Dual clutch design:The drive system is firmer and more suitable for rotten ground. More
800-4A is a self-driving concrete floor grinder. It is one of Xingyi's best-selling ground grinders. High power and high efficiency are a major feature of this grinder, which saves time and effort. The reason for the best-selling.
Brand:
High Tech GrindingItem NO.:
800-4AProduct Origin:
Fujian, ChinaColor:
Black and silverShipping Port:
XiamenLead Time:
7-20 DaysSelf-driving Terrazzo concrete floor grinder
800-4A is a self-driving concrete floor grinder. The speed of the motor and the walking speed of the machine can be adjusted freely, and different operators can achieve a consistent grinding effect without being subjectively affected. According to the formula, the approximate amount of construction in a day can be calculated. It is one of the best-selling ground grinders in Xingyi.
Specifications
Model Name |
800-4A |
Working Width |
800mm |
Voltage |
380V-440V 3 phase |
Motor HP |
WEG motor 15KW |
AC Motor driver |
Delta inverter 18.5KW |
Rotating Speed |
450-1950rpm |
Grinding disc |
256mm*4 |
Ampere |
30.7A |
Weight |
540KG |
★Four-head planetary counter-rotating grinding disc
★Internationally renowned brand WEG motors and Delta inverters
★Self-driving system for easy grinding
★Ramp grinding can carry out 25 degree climbing
★Cruising at a constant speed
★Three-stage weighted iron has high adhesion
★Sheet metal frame and laser cutting
★PE floating dust cover is durable
Company Profile
Our Certificate
FAQ
Q1:Why choose a gear drive system?
A1:Xingyi engineers found that the efficiency of most grinding equipment is extremely low. They rely on the belt tensioning system to drive the grinding head, which consumes part of the power generated by the motor. In addition, the grinding accuracy of most grinding equipment is uncontrollable. Using belt drive system to drive the grinding head will cause slipping, which causes the actual speed of the grinding head to change continuously and cannot achieve constant speed. Gear drive can solve the two problems.
Q2:How to use 800-4A concrete grinder to grind the ground?
A2:
